Superwinch SP35 Powersports 3500lb Winch
The SP 35 Steel Rope Winch is the perfect addition for ATV and UTV enthusiasts needing robust pulling power. This winch boasts a 3,500 pounds pull rating, ensuring reliable performance in sand, mud, or any demanding work environment. Equipped with a 40-foot steel wire rope, it operates on a 12 volt, 1.6 HP permanent magnet motor, delivering efficient dynamic braking. The robust 3-Stage planetary gearing and a 198:1 gear ratio enhance its efficiency, complemented by an ergonomic twist-lock clutch for secure load management. It also features dash-mounted control switches, a wired remote for convenient operation, and a patented drum light for visibility during nighttime use.
Specifications:
- Horsepower: 1.6hp, permanent magnet motor 12V DC
- Fairlead: Stainless steel 4-way roller
- Rated Single Line Pull: 3500lbs
- Rope Length: 7/32″ x 40 ft (5.5.0mm x 12.2m)
- Rope Material: Steel wire
- Patented LED lighted drum
- Brake System: Full load holding automatic brake
- Clutch: Ergonomic twistlock
- Color: Graphite
- Dimensions: 19.29in L × 11.02in D × 9.44in H (490mm L × 280mm D × 240mm H)
- Finish: Powder coated graphite
- Gear Ratio: 198:1
- Drum: 1.96″ x 3.74″
- Gear System: 3-stage planetary
- Frame Material: Steel
- Mounting Bolt Pattern: 4.88in × 3.0in (124mm × 76mm)
- Remote Control: Dash-mounted control switches and handheld remote control
- Warranty: Limited lifetime mechanical / 3 year limited electrical
- Winch Hook: 1/4in, clevis pinned, latched
- Includes all pictured hardware
